kestrel气象仪 PRODUCT DISPLAY

Kestrel5000手持式气象仪

时间:2018-06-30 08:42:43 来源:美国kestrel 点击:11471次

NK5000(Kestrel5000)手持式综合气象仪

·NK5000(Kestrel 5000)是NK4000的完全替代升级型号,可测量即时/更大/平均风速,风温,风寒指数,相对湿度,热应力指数,露点温度,大气压,海拔高度,密度高度,气压趋势,数字指南针



NK5000(Kestrel5000)手持式综合气象仪

·NK5000(Kestrel 5000)是NK4000的完全替代升级型号,可测量即时/更大/平均风速,风温,风寒指数,相对湿度,热应力指数,露点温度,大气压,海拔高度,密度高度,气压趋势,数字指南针

·NK5000-Link还具备Kestrel Link功能,可以将数据无线发送到电脑上或者手机上实时查看当前的数据,传输方式更加灵活多样

·数据存储和下载,自动或手动存储10,000个数据



NK5000(Kestrel5000)手持式综合气象仪产品介绍:

Kestrel 5000手持式气象测量仪是一种非常强大的测量和数据记录的工具,体积小巧,结构紧凑。Kestrel 5000是上一代Kestrel4000的升级产品,具体相同的值得信赖的准确性,可靠性和可用性。可应用于科学研究,施工安全,探险,农业和其他任何需要对现场情况监测的行业或活动。

最新款的Kestrel 5系列手持式气象仪,增加了许多新的功能和选项。如果您对Kestrel 4500比较熟悉的话,就会对其大屏幕、高分辨率、高对比度和字体的可读性等印象深刻。Kestrel 5系列同样包括一个内置的双色背光,超强的聚碳酸酯镜片和AA电池供电,并提供可选的LINK iOS和Android无线连接。像所有的Kestrel手持式气象仪一样,Kestrel 5000通过了跌落测试,防尘测试,防水测试等,能抵御恶劣环境而不会损坏, 因此您可以携带它到任何地方。

除了实时测量当前的环境数据,Kestrel 5000可以跟踪并记录超过10000组带有时间戳的数据,这些数据可以通过无线方式传输到移动设备上,也可以通过Kestrel LiNKDongle或者USB Data Transfer Cable传输到PC / MAC上。


Kestrel 5000手持式气象测量仪可以与Kestrel风向标组合配合使用,这种精密设计的配件可牢固固定在Kestrel三脚架上,或者其他¼-20安装支架。组织在一起后,Kestrel 5500就可以成为一个独立的气象监测站点,可连续记录主要气象参数。通过Kestrel LiNK应用程序(iOS和Android),可以在手机上实时显示各气象参数的数据,手机与气象仪的可视距离2.5米。 Kestrel 5000也可以存放在风向标组合的便携包里进行携带。


NK5000系列所具有的新功能:

功能特点
数据传输到手机能运用在Android和iOS系统上,通过指尖实时把关键数据远程传输到浏览手机和平板电脑上,最远高达100英尺的距离。
可供数据导出,阈值警报和简单的固件更新。(实时传输功能仅Link版可以实现)
蓝牙无线链接稳健,轻松连接到iOS和Android移动设备以及Windows和MAC电脑。(计算机需要可选的Kestrel USB加密狗。)
USB数据传输低调,重量轻,防水电线可连接到Windows和MAC电脑的快速数据上传和固件更新。兼容所有的kestrel5系列。
光滑,坚固耐用的转叶轮小巧,安全的,坚实的叶片安装使得5系列风速仪成为定风向的便携式气象站,(作为可选配件出售)
大而且高对比度的屏幕便捷操作,信息清晰可显的屏幕,高分辨率的显示器,图表图形信息清晰呈现,不易视觉疲劳
双色背光可切换背光颜色成标准白和夜视保持红色(NV),红色的NV背光选择功能有助于用户夜视,减少光亮以避免在夜间演习被发现。
安全电池仓门大容量,O形圈密封门更方便,无需工具安装电池。
耐划痕和破损的显示器刚性,划痕涂层聚碳酸酯镜片保护显示器免受损害
耐腐蚀的电池舱电池是可拆卸的,减少了电池泄漏的损坏。(注:强烈建议使用锂电池,以避免电池完全泄漏。)
直观的用户界面图标导航,直观的键盘,和多种语言,易使用


NK5000(Kestrel5000)手持式综合气象仪测量参数;


海拔、气压、侧风、密度高度、露点温度 、方向、逆风或顺风 、热应力指数 、相对湿度 、压力、温度 、湿球温度(湿度)、 寒风、 风速









技术参数:

测量项目

测量范围

精度

分辨率

风速

0.6~60m/s

±3%

0.1 m/s

空气温度

-29℃-70℃

1℃

0.1℃

相对湿度

5-95%

3%

0.1

气压

300~1100hPa

1.5 hPa/mb

0.1 hPa/mb

海拔

-2000m-9000m

15m

1m

风寒

0.4 to 40 m/s, -45.6 to 10.0 °C

1℃

0.1℃

热力指数

21.1 to 54.4 °C, 0 to 100 %RH

2℃

0.1℃

露点温度

-29.0 to 70.0 °C, 20.0 to 95.0 %RH

2℃

0.1℃

湿球温度

0-37.8℃,5.0 - 95.0 %RH, -2000.0 to 9000.0 hPa,<6000 m

2℃

0.1℃

密度高度

0.0 - 37.8 °C, 5.0 to 95.0 %RH, -2000 to 9000 hPa,<6000 m

75m

1m

操作温度

-45℃-125℃

LCD和电池温度

-10℃-55℃

IP防护等级

IP67防水防尘

电源

AA锂电池(平均400小时)

重量

121g(包括电池)

外形尺寸

127×45×28mm

Kestrel 5000应用范围

    • 田径/户外运动

    • 教育/教学

    • 设施管理

    • 家禽/农业

    • 消防

    • 危险品快速反应

    • 徒步/爬山

    • 工业卫生

    • 法律实施

    • 气象

    • 军事

    • 户外活动组织

    • 科学研究

型号:

Kestrel 5000:0850blk

Kestrel 5000-Link:0850lblk

标准配置

•颈绳

•锂电池(平均寿命400小时)

•保护绳袋

•指导手册

•COC证书


Kestrel Meter 5000 Weather Meter

The Kestrel 5000 Pocket Weather Tracker is Kestrel's handled data logging weather meter.  The Kestrel 5000 replaced the Kestrel 4000 in November of 2015.

Kestrel 5000 is only available in:
•Black: $259
•Black w/ Bluetooth LINK: $319

** The 5000 is the same as the 5500, but has NO WIND DIRECTION.  If you need wind direction, check the Kestrel 5500.


What's new with the Kestrel 5000 over the Kestrel 4000 it replaced:

As for weather reading features, they will be the same.  You won't get a 'better' temperature reading, wind reading, etc, or even more readings than available on the 4000... still the same quality USA made meter backed by a 5 year warranty.  Don't feel the need to rush out and replace your old one, but.... there are some advantages that may or may not effect you.
•Bluetooth LINK work with PC/Mac via Dongle.
•Bluetooth LINK to Smartphones / Mobiel / Android / IOS
•Takes 1 AA battery (instead of 2 AAA)
•Battery door is in the back, sealed away from the motherboard, should your battery leak as was common with all the 4000 series.  All 5000 battery doors are the same and interchangeable.
•Slightly larger and improved higher contrast / resolution screen for any lighting (even sunlight) and easy on your eyes.
•Intuitive user-interface screen navigation
•Multiple Languages (English, French, German, Spanish)
•Scratch and breakage-resistant window
•All meters include both options of Red (NV - Night Vision) & White backlights.
•Slightly bigger, more robust, though not really noticeable difference.
•Roughly 10,000 data points.  4000 series all had under 5000 data points.



The Kestrel 5000 Pocket Weather Meter is the baseline wind and weather meter in the Kestrel 5000 series. While the Kestrel 5000 Pocket Weather Meter is similar in wind and weather monitoring functions available with the Kestrel 3500 Wind Meter, it has the distinct advantage of data storage, graphing functions, and computer interface technology.  It has the capacity to store up to 10,000 data points of weather data, enabling you to track changes in the environment over time, view these changes as graphs on your Kestrel 5000's display, and even upload the data to your PC or Mac. The Kestrel 5000 series is now available with Bluetooth LINK Technology, which allows you to communicate with your Kestrel at a range of up to 100 feet with your Android or iPhone, and maximize the battery life of your weather meter.

Each Bluetooth Meter includes custom communication software designed to quickly and easily configure your data transmission frequency, download logged data, graph data and transfer data to other applications.

As with all 5000 series Kestrel meters, they have both a white backlight, which is great for even daytime use, and a night-vision preserving backlight. The red night vision (NV) backlight incorporates optical filter to reduce overall brightness and minimize blue and green spectrum light to preserve night vision.  (Note: This backlight appears soft greyish pink, not "red", and is still in the visible spectrum, so is not compatible with night-vision equipment.)  Basically, with the red backlight, your eyes don't need to adjust when looking from your meter to the horizon in night time use.

The advantage the Kestrel 5000 provides to scientists, athletes, firefighters, automotive technicians, and agricultural specialists is immeasurable. With Kestrel 5000 technology, you will not only know the current weather conditions, but be able to track changes in the environment and therefore make predictions as to what may happen next.


Calibration:
With the new 5000 series (any) technology, the need to calibrate the RH is highly unlikely.

Kestrel will stand by the RH for 5 years, and will adjust it within that 5 years if needed.

Kestrel will repair, recalibrate or replace any defective product within the warranty period.  “Defective” includes measurements outside of our accuracy spec plus stated drift.


The Kestrel Meter 5000 Includes


•Neck Lanyard
•AA Lithium Battery (Average Life 400 Hours)
•Protective Drawstring Pouch
•Certificate of Conformity (with complete specifications)
•Instruction Manual
•5-Year Warranty



The Kestrel Meter 5000 Weather Meter measures/features
•Barometric pressure
•Pressure trend
•Altitude
•Relative humidity
•Heat stress index
•Dew point
•Wet bulb temperature
•Density altitude
•Wind chill
•Air, water, and snow temperature
•Current wind speed
•Average wind speed
•Maximum wind gust
•Waterproof and floats
•Easy to read, backlit screen with high resolution for even bright sunny conditions.
•Time and date
•Exterior temperature, humidity, and pressure sensors for fast and accurate readings
•Humidity sensor can soon be calibrated in the field via cable or Dongle.
•Minimum, maximum, and average values
•Automatically store measurements, even when the unit is turned off
•Manually store measurements with the press of a button
•Customizable data storage - 10,000 data points
•Graph and recall trends
•Customize screens to display user-selected measurements
•Data charting
•Data upload (with optional interface or Bluetooth)
•Five languages (English, French, Spanish, German, and Italian)
•User-replaceable impeller
•Flip-top impeller cover allows use of other functions while protecting the impeller
•US Patent Nos. 5,783,753 and 5,939,645 and 6,257,074
•All instruments and accessories are completely assembled in the USA



Kestrel5000手持式气象仪使用操作说明书和通讯软件请到下载中心下载
